5 gallons barreled automatic filling machine

1.This filling line specially produces 5 gallons bottled drinking water,whose types(b/h)are:100 type,200type,300type,450type,600type,900type,1200type and 2000 type. 2.ltintegrates bottle washer,filler andsealer into one unit,in order toachieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and leaching areused in bottle washer,Washing solution can boused circularly. 3.The sealer can seal bottle caps automatically carry out bottle feeding washing,sterilizing,filling capping,counting and products discharging.It is a new kind of barreled water auto—producting line,which interates mechanism,electricity and pneunatics technologies together. ModelQGF-100QGF-300QGF-450QGF-600QGF-900QGF-1200QGF-2000Filling heads123481216Volume(L)18.918.918.918.918.918.918.9Barrel size(mm)φ270×490φ270×490φ270×490φ270×490φ270×490φ270×490φ270×490Capacity(B/n)100-200200-240300-40060090012002000Gas pressure(mpa)0.4-0.60.4-0.60.60.60.60.60.6Gas consumption (m³/min)0.370.60.61.22.234.5Motor power(Kw)1.753.224.88.58.58.58.5Rated votage(V)380V/50Hz380V/50Hz380V/50Hz380V/50Hz380V/50Hz380V/50Hz380V/50HzOutlinedimension(mm)3970×650×15503550×800×18002800×1100×18003550×1200×18003800×1100×18003650×1500×18003800×1100×18002200×1860×27002560×2350×27503100×2800×2750Weight(kg)8002800400055007500950011800 5 gallons barreled automatic filling machine
